70DA – (ALUMINIUM)

Please click here to download the 70DA Datasheet logo-adobe-pdf-40x

The 70DA Series is a precision yet versatile shaft encoder manufactured in precision machined aluminium and is sealed to IP66 / IP67 as standard, making it capable of withstanding direct water jet spays at up to 220psi (15 Bar).  For further information, click Product Enquiry below.

Description

Body: Precision Machined Aluminium
Cover: Precision Machined Aluminium
Shaft: Stainless Steel
Bearings: Ballraces
Shaft Sealing: Dependant on environment type (see Ordering Codes)
Protection: (IP66 / IP67)
Operating Temp: -20 to +60°C (Higher on request)
Maximum Speed: 3000 RPM (Higher on request)
Torque: 2.9Ncm (typical)
Inertia: 100gcm2 (typical)
Shaft Loading: Axial = 10N (max)
Radial = 10N (max)
Cable: Screened, oil and salt water proof
Impulse Frequency: Up to 300KHz (depending on model)
Current Consumption: 60mA (typical – without load)
