90FPA – IP65 OR IP66/IP67

The 90FPA Series (in 90mm Frame Size) is an innovative Heavy Duty Industrial – Digitally Programmable Multi-turn Potentiometer. Available in 0-5 volts, 0-10 volts and 4-20mA versions.  For further information, click Product Enquiry below.


Body: Precision Machined Aluminium
Cover: Precision Machined Aluminium
Shaft: Stainless Steel
Bearings: Ballraces
Shaft Sealing: IP65: Sealed front bearing
IP66/IP67: Specialist shaft seal
Protection: Options:
IP65 or
IP66 / IP67
Operating Temp: -20 to +85°C (-40° at extra cost)
Maximum Speed: < 300 m/s2 / 10 to 2000Hz
Torque: < 1000 m/s2 / 6ms
Inertia: 100gcm2 (typical)
Shaft Loading: Axial = 10N (max)
Radial = 10N (max)
Cable: Screened, oil and salt water proof
Current Consumption: 50 to 100mA
